General Sticky Mat
Description
Sticky mat is ideal to use in clean rooms of electronic, pharmaceutical industry, hospitals, laboratories and food industries for contamination control, maintaining a clean environment.
It's highly effective in particle removal and easy-to-use.
Made by environment-friendly 'water-based adhesive'
Grades
- M150 : for mild tack users
- M200 : for standard tack users
- M250 : for critical environment users (High Tack)
Material
Polyethylene Film coated with environment-friendly anti-bacterial 'water-borne acrylic adhesive'
Sizes
18"x36", 24"x36", 18"x45", 26"x45", 36"x36", 36"x45", 36"x60", 36"x72", 600x900mm, 600x1200mm, 900x1200mm etc
*other sizes possible on request
Colors
white, blue, grey, green
Structure of the Product
|
Layer Structure |
Sheet Thickness |
No of Sheets |
Total Thickness |
|---|---|---|---|
|
Top Cover Sheet |
0.040±0.005mm |
1 |
0.040mm |
|
Disposable Sheet |
0.035±0.005mm |
30 |
1.050mm |
|
Bottom Cover Sheet |
0.055±0.005mm |
1 |
0.055mm |
General Properties
|
Item |
Standard |
Measure |
Test Method | |
|---|---|---|---|---|
|
Ball Tack |
M150 |
45±5cm |
45cm |
ASTM D 3121 |
|
M200 |
35±5cm |
35cm |
ASTM D 3121 |
|
|
M250 |
23±5cm |
23cm |
ASTM D 3121 |
|
|
Adhesion |
M150 |
130±40g |
130g |
KSA 1107 |
|
M200 |
180±40g |
180g |
KSA 1107 |
|
|
M250 |
230±40g |
230g |
KSA 1107 |
|
|
Bottom Adhesion |
600±100g |
600g |
KSA 1107 |
|
|
Width |
±5mm |
within |
UBCHEM Method |
|
|
Length |
±5mm |
within |
UBCHEM Method |
|
|
Tensile Strength |
> 1.2kg/cm |
1.5kg/cm |
KSM 3001 |
|
|
Dust Removal |
99% in Five step |
99.9% |
UBCHEM Method |
|
Anti-Bacterial Sticky Mat
Description
Sticky mat is ideal to use in clean rooms of electronic, pharmaceutical industry, hospitals, laboratories and food industries for contamination control, maintaining a clean environment with anti-bacterial function.
It's highly effective in particle removal and easy-to-use.
Made by envrionment-friendly anti-bacterial 'water-based adhesive'
Grades
- HGM150 : for mild tack users
- HGM200 : for standard tack users
- HGM250 : for critical environment users (High Tack)
Material
Polyethylene Film coated with environment-friendly anti-bacterial 'water-borne acrylic adhesive'
Sizes
18"x36", 24"x36", 18"x45", 26"x45", 36"x36", 36"x45", 36"x60", 36"x72", 600x900mm, 600x1200mm, 900x1200mm etc
*other sizes possible on request
Colors
white, blue, grey, green
Structure of the Product
|
Layer Structure |
Sheet Thickness |
No of Sheets |
Total Thickness |
|---|---|---|---|
|
Top Cover Sheet |
0.040±0.005mm |
1 |
0.040mm |
|
Disposable Sheet |
0.045±0.005mm |
30 |
1.350mm |
|
Bottom Cover Sheet |
0.055±0.005mm |
1 |
0.055mm |
General Properties
|
Item |
Standard |
Measure |
Test Method | |
|---|---|---|---|---|
|
Ball Tack |
HGM150 |
45±5cm |
45cm |
ASTM D 3121 |
|
HGM200 |
35±5cm |
35cm |
ASTM D 3121 |
|
|
HGM250 |
23±5cm |
23cm |
ASTM D 3121 |
|
|
Adhesion |
HGM150 |
130±40g |
130g |
KSA 1107 |
|
HGM200 |
180±40g |
180g |
KSA 1107 |
|
|
HGM250 |
230±40g |
230g |
KSA 1107 |
|
|
Bottom Adhesion |
600±100g |
600g |
KSA 1107 |
|
|
Width |
±5mm |
within |
UBCHEM Method |
|
|
Length |
±5mm |
within |
UBCHEM Method |
|
|
Tensile Strength |
> 1.2kg/cm |
1.5kg/cm |
KSM 3001 |
|
|
Dust Removal |
99% in Five step |
99.9% |
UBCHEM Method |
|
Anti-Bacterial Properties
|
Item |
Standard |
Measure |
Test Method |
|---|---|---|---|
|
Bacteria Disinfection |
90% |
92~99% |
FITI Testing Korea |
Anti-Static Sticky Mat
Description
Sticky mat is ideal to use in clean rooms of electronic, pharmaceutical industry, hospitals, laboratories and food industries for contamination control, maintaining a clean environment with anti-static function.
It's highly effective in particle removal and easy-to-use.
Made by environment-friendly anti-static 'water-based adhesive'
Grades
- ASM150 : for mild tack users
- ASM200 : for standard tack users
- ASM250 : for critical environment users (High Tack)
Material
Polyethylene Film coated with environment-friendly anti-static 'water-borne acrylic adhesive'
Sizes
18"x36", 24"x36", 18"x45", 26"x45", 36"x36", 36"x45", 36"x60", 36"x72", 600x900mm, 600x1200mm, 900x1200mm etc
*other sizes possible on request
Colors
white, blue, grey, green
Structure of the Product
|
Layer Structure |
Sheet Thickness |
No of Sheets |
Total Thickness |
|---|---|---|---|
|
Top Cover Sheet |
0.040±0.005mm |
1 |
0.040mm |
|
Disposable Sheet |
0.045±0.005mm |
30 |
1.350mm |
|
Bottom Cover Sheet |
0.055±0.005mm |
1 |
0.055mm |
General Properties
|
Item |
Standard |
Measure |
Test Method | |
|---|---|---|---|---|
|
Ball Tack |
ASM150 |
45±5cm |
48cm |
ASTM D 3121 |
|
ASM200 |
35±5cm |
38cm |
ASTM D 3121 |
|
|
ASM250 |
25±5cm |
28cm |
ASTM D 3121 |
|
|
Adhesion |
ASM150 |
130±40g |
130g |
KSA 1107 |
|
ASM200 |
180±40g |
160g |
KSA 1107 |
|
|
ASM250 |
230±40g |
210g |
KSA 1107 |
|
|
Bottom Adhesion |
600±100g |
600g |
KSA 1107 |
|
|
Width |
±5mm |
within |
UBCHEM Method |
|
|
Length |
±5mm |
within |
UBCHEM Method |
|
|
Tensile Strength |
> 1.2kg/cm |
1.5kg/cm |
KSM 3001 |
|
|
Dust Removal |
99% in Five step |
99.9% |
UBCHEM Method |
|
Anti-Static Properties
|
Item |
Standard |
Measure |
Test Method |
|---|---|---|---|
|
Surface Resistance |
109~11 |
1010 |
ASTM D 257 |
|
Decay Half Life |
within 5 seconds |
3.4 seconds |
JIS L 1094:1997 |
